Classification:Truck Crane

Brand:XCMG

Model:QY70K

Maximum lifting Capacity:70ton

Engine Power:276kw

Engine Brand:Weichai

Engine Model:WD615.338

Engine rated speed:2200r/min

Maximum engine torque:1500/1400 N.m

Engine emission standards:Country III

Minimum rated amplitude:3m

Maximum lifting height of the basic arm:11.2m

Maximum lifting height of the maximum main arm:42m

Longitudinal leg distance:5.75m

Cross-distance of horizontal leg:6.9m

Lift arm extension / shrinkage time:150s

Lifting arm start / fall amplitude time:60s

Main lift speed (no load / full load, single rope):130m/min

Secondary lift speed (no load / full load, single rope):108m/min

RPM:2.0r/min

Driving speed (High / Low):75km/h

Minimum turning radius:12m

Minimum ground clearance:270mm

Close Angle:19°

Leave Angle:13°

Dimension(L*W*H):13500*2800*3540mm
